This machine can produce barbed wire ,barbed wire fence which is widely used in national defense, military, railway, highway, agricultural, animal husbandry and other industries. The materials can be hot dipped galvanized wire, electric galvanized wire ,PVC coated wire etc.
The barbed wire machine have three models: CS-A Double Twisted Barbed Wire Machine,CS-B Single Twisted Barbed Wire Machine,CS-C Reverse Double Twisted Barbed Wire Machine ,
|
|
|
Double Twisted | Single Twisted | Reverse Double Twisted |
Parameter
Machine Model | CS-A | CS-B | CS-C |
Type Of Products | Double Twisted | Single Twisted | Reverse Double Twisted |
Voltage | 3 Phase / 220V /380V/415V /440V/ 50Hz/ 60Hz | ||
Power | 3KW | 2.2KW | 2.2KW |
Productivity | 100-200 Kgs/h | 60-100 Kgs/h | 100-200 Kgs/h |
Barb Space | 3'' 4'' 5'' 6'' 7'' As Required | ||
Strand Wire Diameter | 1.8-3.0mm | 1.6-2.6mm | 1.5-2.8mm |
Barb Wire Diameter | 1.7-2.8mm | 1.6-2.2mm | 1.5-2.6mm |
Wire Materials | Carbon Steel Wire,Galvanized Steel Wire,PVC Coated Wire,Stainless Steel Wire | ||
4 The Application or The Barbed Wire
barbed wire is widely used in banks, and living quarters,
private houses, villas, doors and windows, highways, railway guardrails, and border lines to protect security .
