Wire PVC coating line

Wire PVC coating line is used to produce PVC insulated wire,the customer can produce insulated wire of different size by changing the machine head and related accessories. The extruder and tractor apply YCT series governor motor with big range of speed adjustment;we use the intelligent temperature control instrument to control the temperature of the capstan and head automatically with high sensitivity.The structure of the production line is simple,easy to operate,safe and reliable.

Inquire Now Next Product

Parameter

Model	BSJ-A	BSJ-B
Diameter of wire	1-5mm	1-5mm
Mate rial	PE/PVC	PE/PVC
Main motor power	11kw	22kw
Rewinding motor	3kw	3kw
Electronics brand	Schneider	Schneider
Control system	By button Speed adjustable by inverter Inverter brand:INVT Electronics component: Schneider	By button Speed adjustable by inverter Inverter brand:INVT Electronics component: Schneider
Motor bran d	Chinese famous brand	Chinese famous brand
Production Capacity	5-6t per 8hour	7-8t per 8hour
The water used volume	0.3-1 m3 per hour ( circulation flow)	0.3-1 m3 per hour ( circulation flow)
