Large air filter folding machine

Large air filter folding machine is a mechanical device specially used for folding large air filter elements (referred to as "large air filter"). This machine usually has functions such as automatic paper feeding, pre-cutting and feeding, printing, automatic counting, etc. It can efficiently complete a series of processes such as pneumatic feeding, cutting, humidification and heating, creasing, counting, counting after folding, cooling, etc.

Advantages

Strong applicability:The large air filter folding machine can be adjusted according to different filter specifications, with strong adaptability and can meet diverse product needs.

Improved product quality: These machines are usually equipped with a preheating function to ensure the stability of the filter paper during the folding process, thereby improving the overall quality and performance of the filter

Long service life, can be replaced regularly according to demand, reducing the cost of equipment replacement

Applications:

It is used to purify the air in various large-scale industrial production environments to improve the quality of the production environment. It is also widely used in large buildings and public places. In the field of environmental protection, it is used to treat industrial waste gas and reduce pollutant emissions. It has become an indispensable equipment in modern industry and environmental protection.

Inquire Now

Parameter

Type	600	750	1050
Pleating height	10-75mm	13-75mm	20-75mm
Speed	5-50m/min	5-70m/min	5-50m/min
Heating power	2kw	4kw	4kw
Per-heater power	4kw	6kw	8kw
Discounted shaping power	8kw	6kw	12kw
Motor power	4kw	4kw	5kw
